Projection Objective Lenses: Unique Projects for the Entertainment Industry

Jenoptik designs and produces customized 2D and 3D projection objective lenses for attractions in the biggest theme parks in the world.

Projection lens for entertainment industry
From digital customer desktops to the largest stage and movie theater projector in the world — we develop projection objective lenses for a wide range of systems. You can use the innovative wide-angle and high-aperture objective lenses for cupolas, 3D movie theaters or simulators, for example.

Since 1998, our CoastalOpt® projection objective lenses have been used in the production of world-famous shows such as "Fantasmic Florida", "Animal Kingdom's Tree of Life" and "Aladdin." Each year, we develop our objective lenses further so that you can implement new, unique attractions.

Jenoptik's customers not only include the famous Walt Disney World Resort, but also leisure parks across the globe. For example, we execute projects in the USA, Taiwan, the United Arab Emirates, Japan and China. Our experts will be happy to develop unique projection objective lenses for your shows or 3D productions.

Benefits

  • Works with many projectors
  • All pixels of 4K projectors can be used due to very high contrast levels
  • Decreased number of channels used to cover a dome or simulator surface
  • Reduces costs and improves return on investment
  • Folded design possible
  • In-house testing with Jenoptik Dome Theater

Fields of Application

  • Entertainment industry: soaring and dark rides
  • Simulation and training
  • Giant screen cinema
  • 3D movie theaters
  • Planetarium

Jenoptik Dome Theater

Dome theater for laser projector lens testing

In-house testing and demonstration of Jenoptik projection lenses

The Jenoptik Dome Theater enables testing and demonstrating new laser projection lenses for digital cinemas, planetariums and theme park attractions in-house at Jenoptik site.

The screen is 24 feet in diameter with 12 feet dome radius. The hemispherical screen is elevated five feet abovethe audience which is perfect for testing digital planetarium lenses. The screen is coated with a proprietary high performance surface treatment to match our customer’s preferred 3D projection screens.

The Jenoptik Theater also has a 30 x 16 feet flat sceen for testing digital cinema lenses especially produced for flat sceens.

Projection Lenses - Suitable for following projectors

Suitable for following projectors:

  • Christie D4KLH60
  • Christie D4K3560
  • Christie Roadie HD+35K
  • Christie Boxer 4K30
  • Christie Mirage 304K
  • Barco DP4K-32B
  • Barco HDQ-4K35
  • DP INSIGHT 4K Quad
  • DP Insight Laser 4K
  • DP Insight Dual Laser 4K

JOS4K-1 - Technical Datas

F-Theta High Power Projection Lenses

Planetarium and Giant Screen Solutions | JOS4K-1

Parameters
Horizontal field of view:180°
Vertical field of view:125°
Diagonal field of view:-
Effective focal length:7.5 mm
f#:2.85
MTF @ 66 lp/mm:0.68
Lateral color B-R:< 3.5 µm
F-Theta distortion:< 0.2 %
Transmission:> 77 %
Digital light procession (DLP):1.38“ 3 Chip
Resolution:4096 x 2160 pixel
DLP dimension:30.96 mm x 16.33 mm
Pixel pitch:7.56 µm
Max lumens:45 k
Order Number:JOS4K-1

JOS4K-2 - Technical Datas

F-Theta High Power Projection Lenses

Planetarium and Giant Screen Solutions | JOS4K-2

Parameters
Horizontal field of view:101°
Vertical field of view:53°
Diagonal field of view:114°
Effective focal length:17.5 mm
f#:2.85
MTF @ 66 lp/mm:0.78
Lateral color B-R:< 1 µm
F-Theta distortion:< 0.8 %
Transmission:> 77 %
Digital light procession (DLP):1.38“ 3 Chip
Resolution:4096 x 2160 pixel
DLP dimension:30.96 mm x 16.33 mm
Pixel pitch:7.56 µm
Max lumens:45 k
Order Number:JOS4K-2

JOS4K-4 - Technical Datas

F-Theta High Power Projection Lenses

Planetarium and Giant Screen Solutions | JOS4K-4

Parameters
Horizontal field of view:170°
Vertical field of view:90°
Diagonal field of view:192°
Effective focal length:10.35 mm
f#:2.85
MTF @ 66 lp/mm:0.55
Lateral color B-R:< 3.5 µm
F-Theta distortion:< 1 %
Transmission:> 85 %
Digital light procession (DLP):1.38“ 3 Chip
Resolution:4096 x 2160 pixel
DLP dimension:30.96 mm x 16.33 mm
Pixel pitch:7.56 µm
Max lumens:60k
Order Number:JOS4K-4

0.6x Lens Attachment - Technical Datas

0.6x Lens Attachment

Wide Angle Conversion Lens

Jenoptik’s portfolio of projection lenses is complemented by the 0.6x lens attachment. The wide angle conversion lens which is optionally offered works in conjunction with the projector prime lens.

It allows to increase the image size while maintaining a static projection distance. Reverse, it also facilitates to decrease projection throw distance while maintaining the image size.

Suitable for following projector: SONY VPL-GTZ 270/280 w/Lens VPLL-Z7008 (EFL 13.46 mm - 18 mm)

Parameters
Effective focal length:- 2201 mm
MTF @ 66 lp/mm:Depends on zoom postion of prime lens
Transmission:> 92 %
Magnification0.6x
Order Number:JOSI4K-5CL
